Details:
- 4 Inch Strap
- CHFA4K-16M Flat hook with abrasion clip, hook facing down, on one end, Two inch flat loop sewn on opposite end
- Total Strap Length 1 Ft (12 Inches)
- CW4K-Y20PE 4 Inch 20M Yellow Polyester Tie-Down Webbing With Black Edges
- 16200 lb Break Strength
- 5,400 lb Working Load Limit
- Assembled in the USA
Product Weight: 1.42 lb
$11.29 Each
10+ = $10.24
50+ = $9.24
Looking for Reseller or Volume Pricing? Give us a call at 1-877-360-5528
PRODUCT NOTES:
SPECIAL WARNINGS:
- Tie-downs, Strap Extender, Flat Hook On One End, Flat Sewn Loop On The Opposite End
- Strap Extender Configuration, No Buckle Included With The Product
- Product Is Commonly Used As A Replacement Fixed End For A Ratchet Strap
- Flat Hook On The First End Is Orientated, Hook Facing Down, Relative To The Sewing And Strap Tag
- On The Opposite End, There Is A 2 Inch Long Flat Sewn Loop
- The 2 Inch Flat Sewn Loop Is Formed By Folding The Webbing Flat On Top Of Itself, The Loop Has No Twisting, Narrowing Or Pinching In The Webbing
- 2 Inch Flat Sewn Loops Have A Circumference Of 4 Inches And Can Comfortably Fit Over A 1.25 Inch Diameter Round Bar Or Bolt
- Heavy Duty Flat Hook For Highest Strength And Durability
- Flat Hook Is Made Of Steel And Has A Black Resin Finish
- Flat Hook Has The Standard Configuration And Has An Abrasion Clip At The Strap Connection To Help Prevent Premature Wear
- Strap Is Made With Heavy Duty 20000 Lb Polyester Tie-down Webbing
- Sewn With White Polyester Thread
- Strap Length Is Measured From The Tip Of The Sewn Loop To The Inside Edge Of The Flat Hook
- Sewn In The Standard Method To Meet The Provided Strength Rating
- CTD Strap Warning Label Sewn On The Hook End Of The Strap
| Model | Component | Break Strength | WLL |
|---|---|---|---|
| CW4K-Y20PE | 4 Inch 20M Yellow Polyester Tie-Down Webbing With Black Edges | 20,000 lb | 6,667 lb |
| CHFA4K-16M | 4 Inch 16M Flat Hook With Abrasion Clip, Black | 16,200 lb | 5,400 lb |
-
There are no special warnings for this product. Please see our Safety Warnings page for standard product warnings.
Variations of Product Type 4366
There are no variations of Product Type 4366 currently available.
If you would like assistance with a new variation, email CTD customer service at sales@customtiedowns.com
or Call customer service at 1-877-360-5528, M-F during business hours.
